FRP Perforated Type Cable Trays
Indurotech FRP Perforated Cable Trays are widely used in light electrical and instrumentation applications, offering both reliability and an aesthetically clean appearance. Also known as trough-type trays, they feature multiple perforations at the bottom for effective ventilation and heat dissipation. Their single-piece construction makes manufacturing simpler compared to ladder-type trays, resulting in a more cost-efficient solution. These trays are available in widths ranging from 50 mm to 600 mm, suitable for a variety of installation needs.
FRP Perforated Type Cable Tray System
| Specification | Details |
|---|---|
| Width (mm) | 50 / 75 / 100 / 150 / 225 / 300 / 450 / 600 |
| Height (mm) | 25 / 30 / 50 / 100 |
| Thickness (mm) | 2 mm to 4 mm |
| Length (mm) | 3000 |
| Resin Type | Polyester / Vinyl Ester |
